Push Button (5/32 Push-in Input, 2-Way Valves, Normally Closed)

Pneumadyne manufactures 2-way valves with push-in connections on both the input and output ports for plumbing convenience. Several configurations are available to fit application requirements.

Our highly reliable “0” Series valve, part number A0-20-7, features a swivel input port with 5/32 push-in connection to ease tubing installation and alignment.

The “11” Series valves (part numbers begin with A11) feature a swivel output port and are available with threaded and push-to-connect input ports.

Both styles of valves have an internal poppet design which contributes to a long product life.

Features
  • Push-in connections speed tubing installation
  • Swivel ports are ideal for valve alignment
  • Black anodized valve bodies for corrosion and wear resistance
  • Internal poppet design for long product life
  • High flow
  • Nuts and lockwasher provided

Performance Data

  • Operating Pressure: 0 to 125 psi
  • Flow Rate: Ranges from 17.3 to 33 scfm at 125 psi depending upon the valve selected. Download Performance Data for specific information.

CAD Library

Click here to search for and download a CAD model of this Pneumadyne component on Bimba.com.
