Momentary Toggle (5/32 Push-in Input, 2-Way Valves, Normally Clo

Push-to-connect ports allow for faster tubing connection and valve installation. Pneumadyne manufactures two styles of 2-way normally open valves with push-to-connect ports.

The “0” Series, part number F0-20-7, features a swivel input port and 10-32 (F) output port.

Our “11" Series (part numbers start with F11) feature a swivel output port for positioning purposes.

Both styles of valves have an internal poppet design which contributes to a long product life.

Features
  • Push-to-connect ports ease tubing installation
  • Black anodized valve bodies for corrosion resistance
  • Internal poppet design contributes to long product life
  • Swivel ports accommodate critical valve alignment
  • Miniature size
  • Nuts and lockwasher provided

Performance Data

  • Operating Pressure: 0 to 125 psi
  • Flow Rate: Ranges from 17.3 to 22.1 scfm at 125 psi depending upon the valve selected. Download Performance Data for specific information.

CAD Library

Click here to search for and download a CAD model of this Pneumadyne component on Bimba.com.
