3/8 NPT Thread to Barb Elbow Fittings

Click image to enlarge

Five barbs ranging in size from 1/8 to 3/8 are offered on our Fixed Elbows with 3/8 NPT threads. The Pneu-Edge® style fitting features a single-barb design for a tighter grip and seal ensuring permanent tubing connection. A smoother approach angle also eases tubing installation. Pneumadyne's solderless joint technology eliminates pull-out potential and ensures straight barb alignment.

Features
  • Larger thru-hole for maximized flow
  • Electroless nickel plated for corrosion resistance
  • Smoother approach angle eases tubing installation
  • Recommended for use with Polyurethane tubing
  • Precision machined, high quality fittings

ProductsReturn to Top

Narrow Your Results By:

CAD LibraryReturn to Top

Click here to search for and download a CAD model of this Pneumadyne component on Bimba.com.

Performance DataReturn to Top

  • Operating Pressure: Vacuum to 125 psi
  • Flow Rate: Download Performance Data Spec Sheet for detailed information

Product FilesReturn to Top



Compliance
WarningWarning: Cancer and Reproductive Harm - www.P65warnings.ca.gov
