1/4 NPT (F) Thread to Barb Thread Fittings

Click image to enlarge

Pneumadyne manufactures Fixed Tees with eight barb sizes ranging from 1/16 to 3/8 tube id to fit application requirements. The single-barb design provides a tighter grip and seal than multiple barbs. A smaller shank behind the barb allows polyurethane tubing to relax for a permanent installation without the need for clamps. Our solderless joint technology eliminates pull-out potential and ensures straight barb alignment.

Features
  • Electroless nickel plated for corrosion resistance
  • Larger thru-hole for maximized flow
  • Smoother approach angle eases tubing installation
  • Recommended for use with Polyurethane tubing
  • Precision machined, high quality fittings

Product FilesReturn to Top

ProductsReturn to Top

Narrow Your Results By:

CAD LibraryReturn to Top

Click here to search for and download a CAD model of this Pneumadyne component on Bimba.com.

Performance DataReturn to Top

  • Operating Pressure: Vacuum to 125 psi
  • Flow Rate: Download Performance Data Spec Sheet for detailed information



Compliance
